STRAIGHT CUT INPUT GEAR- 23 TEETH [C-STR230]

Straight cut teeth broach gear for the 1st motion shaft which runs with the straight cut idler and primary gear combinations. This has 23 teeth and one identification ring on actual teeth.

Achievable drop gear ratios:

• 22 tooth primary – 30 tooth idler – 25 tooth input = 1.136-1
• 24 tooth primary – 30 tooth idler – 24 tooth input = 1.0-1
• 23 tooth primary – 30 tooth idler – 23 tooth input = 1.0-1
• 24 tooth primary – 30 tooth idler – 25 tooth input = 1.0416-1
• 23 tooth primary – 30 tooth idler – 24 tooth input = 1.0434-1
• 22 tooth primary – 30 tooth idler – 23 tooth input = 1.045-1
• 23 tooth primary – 30 tooth idler – 25 tooth input = 1.0869-1
• 22 tooth primary – 30 tooth idler – 24 tooth input = 1.09-1
• 24 tooth primary – 30 tooth idler – 23 tooth input = 0.958-1
